SPECIFICATIONS |
AC A |
6/15/60/150/300A ±3% of FS |
AC V |
150/300/600V ±3% of FS |
DC V |
60V ±3% of FS |
Ω |
1/10MΩ(25/250Ω mid-scale)
±2% of scale length |
Temperature |
-20°C~+150°C(with the use of Temperature probe 7060)
±5°C(0°C~+100°C) ±10°C(other ranges) |
Conductor size |
Ø33mm max. |
Frequency respones |
50/60Hz |
Withstand voltage |
3700V AC for 1 minute |
Applicable standards |
IEC 61010-1 CAT.III 300V Pollution degree2
IEC 61010-031 IEC 61010-2-032 |
Power source |
R6P(AA)(1.5V)x1 |
Dimensions |
193(L)x78(W)x39(D)mm |
Weight |
275g approx. |
Accessories |
7066A(Test leads) 8923(Fuse[0.5A/600V])x2
9097(Carrying case) R6P(AA)x1
Instruction manual |
Optional |
7060(Temperature probe)
8008(Multi-tran) |
